Click Below for ACCUTEMP Specifications and Case Studies
ACCUTEMP is a 0.75" O.D. temperature logging tool with integral CCL capability designed specifically for through pack-off/restriction real-time leak detection. Run on our AccuLine conductive slickline or E-Line cable, a real-time digital readout correlation & temperature log at surface ensures quality results. Optimal for leak detection, ACCUTEMP has proven its success and durability in the field since its creation.
LEAK DETECTION SERVICES
A .160" 316L stainless steel conductive slickline with real-time correlation, communication, & control capability for perforating, logging, and mechanical slickline services. AccuLine is used in conjunction with a traditional slickline stuffing box eliminating the need for grease. Warrior System compatible tools run on AccuLine are surface powered and require no batteries. Unlike E-Line, AccuLine can perform traditional slickline operations such as jarring, pulling/setting packoffs and shifting sleeves; making it very cost competitive. With a small equipment footprint, mechanical slickline and real-time surface control & confirmation, AccuLine is quickly becoming a leader in the industry for Slickline and light E-Line applications.
Click Below for AccuLine Specifications and Case Studies
MDM Gas Lift Knock-Up Tool
Developed in the 80's by one of Accu-Line's own, the MDM Gas Lift Knock Up Tool is the only proven successful tool of its kind in the world. Often times gas lift valves will lose their latch/fishing neck, making the valve nearly impossible to pull from the mandrel. With the MDM Gas Lift Knock Up Tool we are able to "knock" the valve upward from the bottom of the gas lift mandrel to allow a latch with our special paired retrieval tool. For years, these tools made their way around the world, yielding positive results and beating out competitors' attempted versions with ease. Now they're here to stay and we at Accu-Line are proud to be the only company in the world to offer this one-of-a-kind service.
Click Below to Access Spec Sheet or Inquire about our Knock Up Tool
Accu-Line in cooperation with TD Tools, Inc. offers sand jet perforating/cutting as a service to our customers. Unlike explosive perforating, sand jetting allows for the continued release of energy and forms a 1-2in. cone shaped perforation tunnel that expands as it protrudes deeper into the formation. Removed material is washed out creating better formation communication for the well. We have an array of different tool sizes and types not only for perforating, but for cutting and clean out as well.
Click Below to Inquire about our Sand Jet Perforating Services
- Cut/Completely Sever
- Tubing Cleanout/ De-scale
Click above arrow to view test video in full screen
AccuApp-quality reporting app
AccuApp was developed to allow company and customer personnel the opportunity to give a fully confidential rating of numerous quality factors on every job.
Rating collected will allow management to assess the quality factor of our personnel, working conditions of the location and risk of the task/job at hand. Accu-Line Engineers, Operator/Assistants and client representatives complete the AccuApp survey after every job.
Accu-Line will be able to share data with customers. This will provide unique insight about their personnel & locations.
from Peak Well Systems
The impact-driven Torque-Action Debris Breaker wellbore cleanup and debris removal tool is deployed downhole to break up concretions of sand and scale which are resisting removal by other methods.
The Torque-Action Debris Breaker tool is jarred down mechanically in the well, with each jar applying a short-duration torque via the unique helically split torque sub. The main torque body comes in 1 1/2-in, 1 7/8-in and, 2 1/2-in sizes and has several different show sizes that can be easily changed on the main body of the tool as the scale is broken down. The debris is recovered by subsequent bailer runs.
To break up persistent sand/scale concretions which have resisted recovery by other methods.
Features & Benefits
Integral sprung torque system which applies torque to the cutting edges with each downward jar
Internal support sleeve to limit loading on the torque spring should the tool become wedged in solids
Left hand threads, where required, to prevent tool back-off down-hole
Comes with different shoe sizes that are changed out on the same main tool body
No other specialist tools required
Overall reduction in time required for descaling, thus reducing intervention time and costs
Production can resume much faster than ever before using alternative methods of descaling
Delivers exceptional cost-effective results compared to other descaling alternatives such as mechanical, chemical or sonic break-down
Full range of broach sizes available (1.700 in - 4.700 in); details upon request.
Kinley Sand Line Cutter Services
for slickline. e-line. cable up to 1/2" O.D.
With many years in the oil & gas industry, Kinley power tools has proven the reliability and success of it's tools. Accu-Line Wireline Services, LLC, in conjunction with Expro Americas, is proud to offer cutting services by use of Kinley Sand Line Cutters.
Accu-Line operators undergo an official Kinley training course before permission is granted to operate any Kinley power tools. A certificate is issued stating tool knowledge and permission to operate once training is completed.
90 minute partitioned timers are used in the cutter assemblies with options to cut slickline, cable, or Electric Line.
Torque Action Debris Breaker
AccuPulse is a slickline-deployed, Tubing-Retrievable Subsurface Safety Valve (TRSV) cleaning system that focuses on the 2 most probable areas of a TRSV, that cause operation malfunction or failure; the Flapper/Seat, the Piston Void.
Utilizing the AccuPulse, we target and effectively clean the two most probable areas that cause Tubing-Retrievable Subsurface Safety Valves (TRSV) to fail/leak, without harm to internal components. Through use of extension subs, the length of the AccuPulse remains fully customizable, allowing us to achieve precise jet location placement and maximum cleaning efficiency on nearly every Tubing-Retrievable Subsurface Safety Valve (TRSV) that exists on the market today.
O.D. (in.): 1.6875”
Positioning: Locks in Nipple Profile of Tubing Retrievable Subsurface Safety Valve
(TRSV) Length: Variable
Spray Pattern: 360 Degrees
Operating Pressure: 2,500psi – 5,000psi
Pump Requirements: >10gpm (0.25 bbl/min. up to 1.00 bbl/min.)
Retrieval / Deployment Method: Slickline
Fluid Type: AccuWash – A low viscosity soft wash fluid developed specifically to be used during AccuPulse operations (SDS available upon request). Customer preferred fluid solutions may also be used.
Click Below to View AccuPulse Animation
AccuPulse Spec Download
AccuWash Spec Download
